IONIQ 20 – LEAK TESTER FOR HIGH VOLUME PRODUCTION
PRODUCTION BATTERY POUCH CELL TESTING

On the basis of its well proven concept of production line QC Testers, ATEQ has developed a new leak tester designed for the specific requirements of high volume production of plastic parts. This instrument is used for the detection of localized moulding faults, insufficient membrane thickness, perforations, etc. This instrument has also proven to be effective on testing pouch battery cells.

The IONIQ is based on discharge current measurement and is able to detect defects up to of 10µm.

APPLICATIONS

MEASUREMENT

FEATURES

SPECIFICATIONS

FACTSHEETS

TECHNOLOGY

IONIQ 20 : APPLICATIONS

Battery pouch cells, plastic bottle caps, plastic packaging, plastic coverings…

IONIQ 20 : MEASUREMENT PRINCIPLE

• The IONIQ measures the current flowing between a patented charged probe and a ground plate placed under the part to be tested.
• The IONIQ uses the % of the nominal voltage (which reflects the discharge current), measured on the part as PASS/FAIL level.
• In a PASS situation (fig 1) : No hole, no weak part, the IONIQ measures a high %. The measured voltage and the nominal voltage are virtually equal. The result is above the reject level, the part has passed the test.
• In a FAIL situation (fig 2) : The IONIQ measures a low %. The measured voltage is significantly below the nominal voltage. The result is below the reject level, the part has failed the test.
• Test limitations: short probe-part-plate distance, electrical insulation from environment.

IONIQ 20 : FEATURES

• Integrated ionising high voltage generator (5 to 27.3 kV)
• Reject levels as % of nominal voltage (0 to 100%)
• Monitoring and protection of high voltage generator
• Limitation of the current rating
• Speed: Minimum cycle time 0.6s
• I/O’s for instrument control and results
• 32 programs
• Remote control allows the test module to be closed to the test part
 • And: Language selection, customization of test …

IONIQ 20 : SPECIFICATIONS

  • HIGH VOLTAGE GENERATOR

    • Integrated and adjustable according to application (5 to 27.3 kV)
  • TEMPERATURE

    • Operating : + 10°C at + 45°C
    • Storage : 0°C at + 60°C
  • POWER SUPPLY

    • 24 VDC/ 1A
      Note: The instrument needs a good ground connection

  • OPTIONAL

    • Save results module
    • Standard resistor box with 2 values

  • INTERFACE
    Programming via remote control 7 inputs / 5 outputs for PLC controlled applications.

    • Inputs : Optically isolated.
      24 V – 10 mA maximum or dry contact.
    • Outputs : Relay output
      Rated 48 V / 200 mA maximum.

  • DIMENSIONS

    • Box dimensions :
      Dimensions : H x L x P = 136 x 250 x 255 mm
      Weight : 8 kg
    • Remote control :
      Dimensions : H x L x P = 250 x 250 x 60 mm
      Weight : 2.8 kg

IONIQ 20 : FACTSHEETS

Detailed information about the IONIQ 20 including features, specifications, etc.

IONIQ20 Brochures – English

IONIQ20 : TECHNOLOGY

A high voltage loaded sharp end is applied next to an earth connected base and in between lays the plastic part we test. Should a hole exist in the part, ions will start moving from the earth to the sharp end. This will result in a loss of power and be translated into a leak.
While this method does not quantify the leak rate in terms of cc/min for example, it is the fastest ever invented to detect a leak in a go / no go process.
We have achieved cycle times of less than 7/10 of a second.

Leak Ranges: Depends on the size of the hole and the material of the part
Accuracy: Depends on the size of the hole and the material of the part
